Graceful removal of the OpenEBS cStor disk pool from the cluster

Kubernetes

Mar 05, 2023

OpenEBS takes volume provisioning to the next level. It is due to its dynamic nature as well as helpful replication capabilities. However, from time to time it might be required to perform some maintenance work in the cluster that would require taking a node out. This has to be done with tremendous care and caution so no data is corrupted or lost.

Reducing replicas gracefully

I use OpenEBS cStor as the default storage engine. CStorPoolCluster has been configured to have 3 CStorPoolInstances, on each worker node. Now it's time to temporarily reduce the number of those instances to 2. Issuing the following command will list them.

❯ kubectl get cstorpoolinstances.cstor.openebs.io
NAME                           HOSTNAME   FREE     CAPACITY   READONLY   PROVISIONEDREPLICAS   HEALTHYREPLICAS   STATUS   AGE
openebs-cstor-disk-pool-d5rg   vm0102     87400M   90100M     false      4                     4                 ONLINE   34d
openebs-cstor-disk-pool-pxgl   vm0302     87400M   90100M     false      4                     4                 ONLINE   34d
openebs-cstor-disk-pool-rvl2   vm0202     87400M   90100M     false      4                     4                 ONLINE   33d

‌Due to the removal of a node, I have to decommission openebs-cstor-disk-pool-pxgl pool. The pool is used by multiple PVCs, therefore have to edit the CStorVolumeConfig of each PVC to get rid of the pool.

❯ kubectl get cstorvolumeconfigs.cstor.openebs.io
NAMESPACE   NAME                                       CAPACITY   STATUS   AGE
openebs     pvc-48b1eaaa-8874-4d56-9c3a-1240e30d861c   4Gi        Bound    33d
openebs     pvc-5f57319d-a744-44fa-9aa1-33cfcadb649f   8Gi        Bound    33d
openebs     pvc-863aa630-5368-4400-9c01-e965d17c5aeb   4Gi        Bound    33d
openebs     pvc-8d8cb8cb-9e13-4a3a-8f12-d5a19b4afb8b   4Gi        Bound    33d

Editing volume config will give us output similar to the following one.

❯ kubectl edit cstorvolumeconfigs.cstor.openebs.io pvc-48b1eaaa-8874-4d56-9c3a-1240e30d861c
apiVersion: cstor.openebs.io/v1
kind: CStorVolumeConfig
metadata:
  annotations:
    openebs.io/persistent-volume-claim: datadir-mysql-innodbcluster-0
    openebs.io/volume-policy: ""
    openebs.io/volumeID: pvc-48b1eaaa-8874-4d56-9c3a-1240e30d861c
  creationTimestamp: "2023-01-14T20:37:31Z"
  finalizers:
  - cvc.openebs.io/finalizer generation: 6
  labels:
    cstor.openebs.io/template-hash: "251293062"
    openebs.io/cstor-pool-cluster: openebs-cstor-disk-pool
    openebs.io/pod-disruption-budget: openebs-cstor-disk-poolrb5qk
  name: pvc-48b1eaaa-8874-4d56-9c3a-1240e30d861c
  namespace: openebs
  resourceVersion: "538165"
  uid: e441ef25-4fd1-4fcf-9e96-597f79f812db
publish:
  nodeId: vm0202
spec:
  capacity:
    storage: 4Gi
  cstorVolumeRef:
    apiVersion: cstor.openebs.io/v1
    kind: CStorVolume name: pvc-48b1eaaa-8874-4d56-9c3a-1240e30d861c
    namespace: openebs
    resourceVersion: "537566"
    uid: 3037d679-b74f-4fdf-8279-7c31d4ff59e2
  policy:
    provision:
      replicaAffinity: false
    replica: {}
    replicaPoolInfo:
    - poolName: openebs-cstor-disk-pool-d5rg
    - poolName: openebs-cstor-disk-pool-pxgl
    - poolName: openebs-cstor-disk-pool-rvl2
    target:
      auxResources:
        limits:
          cpu: "0"
          memory: "0"
        requests:
          cpu: "0"
          memory: "0"

The crucial part here is to remove openebs-cstor-disk-pool-pxgl from the replicaPoolInfo list. It has to be done for each CStorVolumeConfig.

Once it is done, there should be no replicas in the pool.

❯ kubectl get cstorpoolinstances.cstor.openebs.io
NAME                           HOSTNAME   FREE     CAPACITY   READONLY   PROVISIONEDREPLICAS   HEALTHYREPLICAS   STATUS   AGE
openebs-cstor-disk-pool-d5rg   vm0102     87400M   90100M     false      4                     4                 ONLINE   34d
openebs-cstor-disk-pool-pxgl   vm0302     90G      90117M     false      0                     0                 ONLINE   34d
openebs-cstor-disk-pool-rvl2   vm0202     87400M   90100M     false      4                     4                 ONLINE   33d

We are ready to delete it.

❯ kubectl delete cstorpoolinstances.cstor.openebs.io openebs-cstor-disk-pool-pxgl
cstorpoolinstance.cstor.openebs.io "openebs-cstor-disk-pool-pxgl" deleted

‌Now we should have two disk pools only. Describing CStorPoolClusters will show the number of healthy and desired instances, so 2 and 3 respectively.

❯ kubectl get cstorpoolclusters.cstor.openebs.io
NAME                      HEALTHYINSTANCES   PROVISIONEDINSTANCES   DESIREDINSTANCES   AGE
openebs-cstor-disk-pool   2                  2                      3                  34d

It's time to update CStorPoolClusters.

❯ kubectl edit cstorpoolclusters.cstor.openebs.io openebs-cstor-disk-pool
apiVersion: cstor.openebs.io/v1
kind: CStorPoolCluster
metadata:
  creationTimestamp: "2023-01-13T21:31:16Z"
  finalizers:
  - cstorpoolcluster.openebs.io/finalizer
  generation: 21
  name: openebs-cstor-disk-pool
  namespace: openebs
  resourceVersion: "18193885"
  uid: b9a7dfe4-5f2f-43b5-aeef-af03af3d87f1
spec:
  pools:
  - dataRaidGroups:
    - blockDevices:
      - blockDeviceName: blockdevice-a251ba13122b4b5f8c2ce9471cf4b03e
    nodeSelector:
      kubernetes.io/hostname: vm0102
    poolConfig:
      dataRaidGroupType: stripe
  - dataRaidGroups:
    - blockDevices:
      - blockDeviceName: blockdevice-19d2d2fdc1c0e274aa3ba199d8fba897
    nodeSelector:
      kubernetes.io/hostname: vm0302
    poolConfig:
      dataRaidGroupType: stripe
  - dataRaidGroups:
    - blockDevices:
      - blockDeviceName: blockdevice-2806021afad58e5ef20c5c82b78fd943
    nodeSelector:
      kubernetes.io/hostname: vm0202
    poolConfig:
      dataRaidGroupType: stripe

‌ We have to get rid of dataRaidGroup containing the hostname vm0302 and block device blockdevice-19d2d2fdc1c0e274aa3ba199d8fba897 from the pools list.

❗ If a node is already lost, OpenEBS won't let us remove the hostname and device from the list. This requires additional steps to take, see Node is lost before disk pool removal.

The block device should now be Unclaimed.

❯ kubectl get bd
NAME                                           NODENAME   SIZE          CLAIMSTATE   STATUS   AGE
blockdevice-19d2d2fdc1c0e274aa3ba199d8fba897   vm0302     99998934528   Unclaimed    Active   34d
blockdevice-2806021afad58e5ef20c5c82b78fd943   vm0202     99998934528   Claimed      Active   34d
blockdevice-a251ba13122b4b5f8c2ce9471cf4b03e   vm0102     99998934528   Claimed      Active   34d

Now it can be removed.

❯ kubectl delete bd blockdevice-19d2d2fdc1c0e274aa3ba199d8fba897
blockdevice.openebs.io "blockdevice-19d2d2fdc1c0e274aa3ba199d8fba897" deleted

We are ready to drain nodes.

Node is lost before disk pool removal

Planned maintenance is the most desirable way of making things run healthy. However, rarely happen random unplanned events. The disasters for instance. In such cases, there is no way to perform graceful removal as the node is already lost.

OpenEBS has finalizers that perform clean-up actions once a resource is removed. However, when the finalizer is not able to run an action, it gets stuck and prevents the removal of the disk pool from the cluster. In such a case it is required to edit the cStor volume replica related to the lost pool and remove the finalizer manually.

❯ kubectl get cstorvolumereplicas.cstor.openebs.io
NAME                                                                    ALLOCATED   USED    STATUS    AGE
pvc-5ea36f92-daec-4ba8-a650-456b1b97b17a-openebs-cstor-disk-pool-pxgl   873M        4.79G   Offline   4d12h
pvc-5ea36f92-daec-4ba8-a650-456b1b97b17a-openebs-cstor-disk-pool-d5rg   873M        4.79G   Healthy   4d12h
pvc-5ea36f92-daec-4ba8-a650-456b1b97b17a-openebs-cstor-disk-pool-rvl2   873M        4.79G   Healthy   4d12h
pvc-5f57319d-a744-44fa-9aa1-33cfcadb649f-openebs-cstor-disk-pool-pxgl   226M        758M    Offline   14d
pvc-5f57319d-a744-44fa-9aa1-33cfcadb649f-openebs-cstor-disk-pool-d5rg   227M        758M    Healthy   48d
pvc-5f57319d-a744-44fa-9aa1-33cfcadb649f-openebs-cstor-disk-pool-rvl2   227M        758M    Healthy   48d
pvc-a274c159-eeb4-4d7c-9c22-bc8df66e9ae9-openebs-cstor-disk-pool-pxgl   189M        512M    Offline   4d12h
pvc-a274c159-eeb4-4d7c-9c22-bc8df66e9ae9-openebs-cstor-disk-pool-d5rg   189M        512M    Healthy   4d12h
pvc-a274c159-eeb4-4d7c-9c22-bc8df66e9ae9-openebs-cstor-disk-pool-rvl2   189M        511M    Healthy   4d12h

Here following volume replicas need treatment:

pvc-5ea36f92-daec-4ba8-a650-456b1b97b17a-openebs-cstor-disk-pool-pxgl,
pvc-5f57319d-a744-44fa-9aa1-33cfcadb649f-openebs-cstor-disk-pool-pxgl, and
pvc-a274c159-eeb4-4d7c-9c22-bc8df66e9ae9-openebs-cstor-disk-pool-pxgl.

When editing the resource, we have to find finalizers list.

❯ kubectl edit cstorvolumereplicas.cstor.openebs.io pvc-5ea36f92-daec-4ba8-a650-456b1b97b17a-openebs-cstor-disk-pool-pxgl
apiVersion: cstor.openebs.io/v1
kind: CStorVolumeReplica
metadata:
  annotations:
    cstorpoolinstance.openebs.io/hostname: vm0302
    creationTimestamp: "2023-02-27T20:13:52Z"
    finalizers:
    - cstorvolumereplica.openebs.io/finalizer
    generation: 13086
    labels:
      cstorpoolinstance.openebs.io/name: openebs-cstor-disk-pool-pxgl

And remove the following line:

- cstorvolumereplica.openebs.io/finalizer

This will allow CStorVolume to scale down.

Now, we can update CStorPoolClusters and remove unreachable resources.

Conclusion

Installing OpenEBS on a cluster and then configuring it is an easy task. However, maintenance can be quite difficult and requires a lot of insight. I strongly encourage you to seek troubleshooting guides before going down the rabbit hole.

Troubleshooting OpenEBS - cStor | OpenEBS Docs
